Datos del producto:
Pago y Envío Términos:
|
| Capacidad nominal: | 12 toneladas | Neumático: | 26.5-25 |
|---|---|---|---|
| Altura de vertido máximo: | 4150m m | Motor: | Weichai |
| Potencia del motor: | 199KW | Peso operativo: | 25,5 TONELADAS |
| Dimensión: | 9500*3130*3800mm | tipo de mudanza: | Cargador de ruedas |
Wenyang machinery WY978J 12Ton wheel loader with log grapple suitable for big diameter wood log
Excellent performance
▼Engine ---Weichai styer WD10G270E201 power 199kw,high-end engine ,high efficiency and low noise cooling technology . Powerful ,reliable performance .
▼Tnak----reinforced structure to ensure the tank intensity under vibration .Fuel tank capacity is 280L,can meet the oil demand after a long time and continuous operation .
▼Counterweight ---large steering angle and thick slabs counterweight ,not only reliable but also practical.
▼Boom cylinder ,the rotating bucket cylinder-reinforced type cylinder piston rod.
▼Drive axle-increase ,enhanced professional drive axle, bearing gears ,wheels hub, increase block bearing ,use special heavy vehicle brake materials and advanced hydraulic technology .Effectively guarantee the brake performance ,reduce the fault rate.
▼Boom---lengthen ,double-thick type boom, shift within the fulcrum force ,increase and guarantee the strength.
▼Front and rear frame –special design and manufacture of the frame ,with a strong ability to support and lateral stability of the vehicle .
▼Tires ---front wheel for forestry special 26.5R25 steel wire tire.
| Item | Unit | Specification | |
| Engine rated power | kw | 199 | |
| Overall dimension(L*W*H) | With extended arm | mm | 9500*3130*3800 |
| Maximum dump height | Flat at the bottom of the fork | mm | 4150 |
| Fork tiled down | mm | 3400 | |
| Rated load | kg | 12000 | |
| Total weight | kg | 25500 | |
| Dimensions of fork | L*W*H | mm | 1986*2660*1851 |
| Distance of clamp fork | mm | 2600 | |
| Diameter range | mm | 1000-2000 | |
| Dumping reach | Ordinary arm | mm | 2050 |
| Maximum torque | N.m | 920 | |
| Turing angle | . | 32 | |
| Biggest opening size | mm | 2250 | |
| Max.climbing gradient | . | ≤ 25 | |
| Min.turing radius | mm | 7250 | |
| Wheelbase | mm | 2510 | |
| Tread | mm | 3550 | |
| Min. ground clearance | mm | 680 | |
| Pallet fork travel angle | . | 95 | |
| Turing radius when fork at haul location | mm | 6470 | |
| Fuel tank capacity | L | 280 | |
| Hydraulic fuel tank capacity | L | 280 | |
| Tyre specification | 26.5-25 | ||
